CD197 antibody | 4B12
Rat anti Mouse CD197:Alexa Fluor® 488
Rat anti Mouse CD197:Alexa Fluor® 647
Rat anti Mouse CD197:FITC
Rat anti Mouse CD197
Rat anti Mouse CD197:RPE
- Product Type
- Monoclonal Antibody
- Clone
- 4B12
- Isotype
- IgG2a
| Product Code | Applications | Pack Size | List Price | Quantity |
|---|---|---|---|---|
| MCA2367A488 | F | 100 Tests/1ml |
|
|
| MCA2367A488T | F | 25 Tests/0.25ml |
|
|
| MCA2367A647 | F | 100 Tests/1ml |
|
|
| MCA2367F | F | 0.1 mg |
|
|
| MCA2367GA | F IP | 0.1 mg |
|
|
| MCA2367PE | F | 100 Tests |
|
Rat anti Mouse CD197 antibody, clone 4B12 recognizes murine C-C chemokine receptor type 7, also known as CD197, Epstein-Barr virus-induced G-protein coupled receptor 1, CCR7 or MIP-3 beta receptor. CD197 is a 354 amino acid ~43 kDa member of the G-protein coupled receptor family. In mice, CD197 is expressed on most naïve T cells, a subset of memory T cells, B cells, mature dendritic cells, NK cells, a subset of thymocytes and CD34+ macrophage progenitor cells.
CD197 is a functional receptor for chemokines CCL21 and CCL19. The receptor plays an important role in regulating the trafficking and homing of lymphocytes and dendritic cells to secondary lymphoid organs.
Rat anti Mouse CD197 antibody, clone 4B12 does not block the binding of the ligand to CD197.
CD197 is a functional receptor for chemokines CCL21 and CCL19. The receptor plays an important role in regulating the trafficking and homing of lymphocytes and dendritic cells to secondary lymphoid organs.
Rat anti Mouse CD197 antibody, clone 4B12 does not block the binding of the ligand to CD197.
Product Details
- Target Species
- Mouse
- Product Form
- Purified IgG conjugated to Alexa Fluor® 488 - liquid
- Product Form
- Purified IgG conjugated to Alexa Fluor® 647 - liquid
- Product Form
- Purified IgG conjugated to Fluorescein Isothiocyanate Isomer 1 (FITC) - liquid
- Product Form
- Purified IgG - liquid
- Product Form
- Purified IgG conjugated to R. Phycoerythrin (RPE) - lyophilized
- Reconstitution
- Reconstitute with 1.0 ml distilled water
- Preparation
- Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
- Preparation
- Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
- Preparation
- Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
- Preparation
- Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
- Preparation
- Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
- Buffer Solution
- Phosphate buffered saline
- Buffer Solution
- Phosphate buffered saline
- Buffer Solution
- Phosphate buffered saline
- Buffer Solution
- Phosphate buffered saline
- Buffer Solution
- Phosphate buffered saline
- Preservative Stabilisers
0.09% Sodium Azide 1% Bovine Serum Albumin - Preservative Stabilisers
0.09% Sodium Azide 1% Bovine Serum Albumin - Preservative Stabilisers
0.09% Sodium Azide 1% Bovine Serum Albumin - Preservative Stabilisers
0.09% Sodium Azide - Preservative Stabilisers
0.09% Sodium Azide 1% Bovine Serum Albumin 5% Sucrose - Carrier Free
- Yes
- Immunogen
- CCR7 rat basophilic leukaemia (RBL)-2H3 transfectants.
- Approx. Protein Concentrations
- IgG concentration 0.05 mg/ml
- Approx. Protein Concentrations
- IgG concentration 0.05 mg/ml
- Approx. Protein Concentrations
- IgG concentration 0.1 mg/ml
- Approx. Protein Concentrations
- IgG concentration 1.0 mg/ml
- Fusion Partners
- Spleen cells from immunised Lou/c rats were fused with cells of the mouse X63.Ag8.653 myeloma cell line.
Storage Information
- Storage
- This product is shipped at ambient temperature. It is recommended to aliquot and store at -20°C on receipt. When thawed, aliquot the sample as needed. Keep aliquots at 2-8°C for short term use (up to 4 weeks) and store the remaining aliquots at -20°C.
Avoid repeated freezing and thawing as this may denature the antibody. Storage in frost-free freezers is not recommended. This product is photosensitive and should be protected from light. - Storage
- This product is shipped at ambient temperature. It is recommended to aliquot and store at -20°C on receipt. When thawed, aliquot the sample as needed. Keep aliquots at 2-8°C for short term use (up to 4 weeks) and store the remaining aliquots at -20°C.
Avoid repeated freezing and thawing as this may denature the antibody. Storage in frost-free freezers is not recommended. This product is photosensitive and should be protected from light. - Storage
- This product is shipped at ambient temperature. It is recommended to aliquot and store at -20°C on receipt. When thawed, aliquot the sample as needed. Keep aliquots at 2-8°C for short term use (up to 4 weeks) and store the remaining aliquots at -20°C.
Avoid repeated freezing and thawing as this may denature the antibody. Storage in frost-free freezers is not recommended. This product is photosensitive and should be protected from light. - Storage
- This product is shipped at ambient temperature. It is recommended to aliquot and store at -20°C on receipt. When thawed, aliquot the sample as needed. Keep aliquots at 2-8°C for short term use (up to 4 weeks) and store the remaining aliquots at -20°C.
Avoid repeated freezing and thawing as this may denature the antibody. Storage in frost-free freezers is not recommended. - Storage
- Store at +4oC.
DO NOT FREEZE
This product should be stored undiluted. This product is photosensitive and should be protected from light. Should this product contain a precipitate we recommend microcentrifugation before use. - Guarantee
- 12 months from date of despatch
- Guarantee
- 12 months from date of despatch
- Guarantee
- 12 months from date of despatch
- Guarantee
- 12 months from date of despatch
- Guarantee
- 12 months from date of despatch
More Information
- UniProt
- P47774
- Entrez Gene
- Ccr7
- GO Terms
- GO:0016021 integral to membrane
- GO:0006935 chemotaxis
- GO:0006955 immune response
- GO:0009897 external side of plasma membrane
- GO:0016493 C-C chemokine receptor activity
- Acknowledgements
- This product is provided under an intellectual property licence from Life Technologies Corporation. The transfer of this product is contingent on the buyer using the purchase product solely in research, excluding contract research or any fee for service research, and the buyer must not sell or otherwise transfer this product or its components for (a) diagnostic, therapeutic or prophylactic purposes; (b) testing, analysis or screening services, or information in return for compensation on a per-test basis; (c) manufacturing or quality assurance or quality control, or (d) resale, whether or not resold for use in research. For information on purchasing a license to this product for purposes other than as described above, contact Life Technologies Corporation, 5791 Van Allen Way, Carlsbad CA 92008 USA or outlicensing@thermofisher.com
- Acknowledgements
- This product is provided under an intellectual property licence from Life Technologies Corporation. The transfer of this product is contingent on the buyer using the purchase product solely in research, excluding contract research or any fee for service research, and the buyer must not sell or otherwise transfer this product or its components for (a) diagnostic, therapeutic or prophylactic purposes; (b) testing, analysis or screening services, or information in return for compensation on a per-test basis; (c) manufacturing or quality assurance or quality control, or (d) resale, whether or not resold for use in research. For information on purchasing a license to this product for purposes other than as described above, contact Life Technologies Corporation, 5791 Van Allen Way, Carlsbad CA 92008 USA or outlicensing@thermofisher.com
- Regulatory
- For research purposes only
Applications of CD197 antibody
| Application Name | Verified | Min Dilution | Max Dilution |
|---|---|---|---|
| Flow Cytometry | Neat * | ||
| Flow Cytometry | Neat | 1/10 | |
| Flow Cytometry | Neat * | ||
| Flow Cytometry | 1/25 | 1/100 | |
| Immunoprecipitation | |||
| Flow Cytometry | Neat |
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
- Flow Cytometry
- Use 20ul of the suggested working dilution to label 106 cells in 100ul.
The Fc region of monoclonal antibodies may bind non-specifically to cells expressing low affinity Fc receptors. This may be reduced by using SeroBlock FcR (- Flow Cytometry
- Use 10ul of the suggested working dilution to label 106 cells in 100ul
- Flow Cytometry
- Use 20ul of the suggested working dilution to label 106 cells in 100ul.
The Fc region of monoclonal antibodies may bind non-specifically to cells expressing low affinity Fc receptors. This may be reduced by using SeroBlock FcR (BUF041A/B).- Flow Cytometry
- Use 10ul of the suggested working dilution to label 106 cells in 100ul
- Flow Cytometry
- Use 20ul of the suggested working dilution to label 106 cells in 100ul.
The Fc region of monoclonal antibodies may bind non-specifically to cells expressing low affinity Fc receptors. This may be reduced by using SeroBlock FcR (BUF041A/B).
Copyright © 2022 Bio-Rad Antibodies (formerly AbD Serotec)
Secondary Antibodies Available
| Description | Product Code | Applications | Pack Size | List Price | Quantity |
|---|---|---|---|---|---|
| Goat anti Rat IgG:Alk. Phos. (Mouse Adsorbed) | STAR131A | C E P WB | 1 ml |
|
|
| Goat anti Rat IgG:Biotin (Mouse Adsorbed) | STAR131B | C E IF P WB | 0.5 mg |
|
|
| Rabbit F(ab')2 anti Rat IgG:Dylight®800 | STAR16D800GA | F IF WB | 0.1 mg |
|
|
| Rabbit F(ab')2 anti Rat IgG:FITC | STAR17B | F | 1 mg |
|
|
| Rabbit F(ab')2 anti Rat IgG:HRP | STAR21B | C E P RE | 1 mg |
|
|
| Goat F(ab')2 anti Rat IgG:FITC (Mouse Adsorbed) | STAR69 | F | 0.5 ml |
|
|
| Goat anti Rat IgG:DyLight®650 (Mouse Adsorbed) | STAR71D650 | F IF | 0.1 mg |
|
|
| Goat anti Rat IgG:Dylight®800 (Mouse Adsorbed) | STAR71D800GA | F IF WB | 0.1 mg |
|
|
| Goat anti Rat IgG:HRP (Mouse Adsorbed) | STAR72 | C E P | 0.5 mg |
|
|
| Goat F(ab')2 anti Rat IgG:RPE (Mouse Adsorbed) | STAR73 | F | 0.5 ml |
|
Negative Isotype Controls Available
| Description | Product Code | Applications | Pack Size | List Price | Quantity |
|---|---|---|---|---|---|
| Rat IgG2a Negative Control:Alexa Fluor® 488 | MCA1212A488 | F | 100 Tests/1ml |
|
|
| Rat IgG2a Negative Control:Alexa Fluor® 647 | MCA1212A647 | F | 100 Tests/1ml |
|
|
| Rat IgG2a Negative Control:FITC | MCA1212F | F | 100 Tests |
|
|
| Rat IgG2a Negative Control | MCA1212 | E F | 1 ml |
|
|
| Rat IgG2a Negative Control:RPE | MCA1212PE | F | 100 Tests |
|
Useful Reagents Available
| Description | Product Code | Applications | Pack Size | List Price | Quantity |
|---|---|---|---|---|---|
| Mouse Seroblock FcR | BUF041A | F | 0.1 mg |
|
|
| Mouse Seroblock FcR | BUF041B | F | 0.5 mg |
|
|
| Mouse Seroblock FcR | BUF041A | F | 0.1 mg |
|
|
| Mouse Seroblock FcR | BUF041B | F | 0.5 mg |
|
Product Specific References
References for CD197 antibody
-
Ritter, U. et al. (2004) Analysis of the CCR7 expression on murine bone marrow-derived and spleen dendritic cells.
J Leukoc Biol. 76 (2): 472-6.
