CD197 antibody | 4B12

100% Secure


Rat anti Mouse CD197:Alexa Fluor® 488

Rat anti Mouse CD197:Alexa Fluor® 647

Rat anti Mouse CD197:FITC

Rat anti Mouse CD197

Rat anti Mouse CD197:RPE

Product Type
Monoclonal Antibody
Clone
4B12
Isotype
IgG2a
Product CodeApplicationsDatasheetMSDSPack SizeList PriceQuantity
MCA2367A488T F 25 Tests/0.25ml
MCA2367A488 F 100 Tests/1ml
MCA2367A647T F 25 Tests/0.25ml
MCA2367A647 F 100 Tests/1ml
MCA2367F F 0.1 mg
MCA2367GA F IP 0.1 mg
MCA2367PET F 25 Tests
MCA2367PE F 100 Tests
Rat anti Mouse CD197 antibody, clone 4B12 recognizes murine C-C chemokine receptor type 7, also known as CD197, Epstein-Barr virus-induced G-protein coupled receptor 1, CCR7 or MIP-3 beta receptor. CD197 is a 354 amino acid ~43 kDa member of the G-protein coupled receptor family. In mice, CD197 is expressed on most naïve T cells, a subset of memory T cells, B cells, mature dendritic cells, NK cells, a subset of thymocytes and CD34+ macrophage progenitor cells.

CD197 is a functional receptor for chemokines CCL21 and CCL19. The receptor plays an important role in regulating the trafficking and homing of lymphocytes and dendritic cells to secondary lymphoid organs.

Rat anti Mouse CD197 antibody, clone 4B12 does not block the binding of the ligand to CD197.

Product Details

Target Species
Mouse
Product Form
Purified IgG conjugated to Alexa Fluor® 488 - liquid
Product Form
Purified IgG conjugated to Alexa Fluor® 647 - liquid
Product Form
Purified IgG conjugated to Fluorescein Isothiocyanate Isomer 1 (FITC) - liquid
Product Form
Purified IgG - liquid
Product Form
Purified IgG conjugated to R. Phycoerythrin (RPE) - lyophilized
Reconstitution
Pack Size: 25 Tests
Reconstitute in 0.25 ml disilled water
Pack Size: 100 Tests
Reconstitute with 1.0 ml distilled water
Preparation
Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
Preparation
Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
Preparation
Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
Preparation
Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
Preparation
Purified IgG prepared by affinity chromatography on Protein G from tissue culture supernatant
Buffer Solution
Phosphate buffered saline
Buffer Solution
Phosphate buffered saline
Buffer Solution
Phosphate buffered saline
Buffer Solution
Phosphate buffered saline
Buffer Solution
Phosphate buffered saline
Preservative Stabilisers
0.09%Sodium Azide
1%Bovine Serum Albumin
Preservative Stabilisers
0.09%Sodium Azide
1%Bovine Serum Albumin
Preservative Stabilisers
0.09%Sodium Azide
1%Bovine Serum Albumin
Preservative Stabilisers
0.09%Sodium Azide
Preservative Stabilisers
0.09%Sodium Azide
1%Bovine Serum Albumin
5%Sucrose
Carrier Free
Yes
Immunogen
CCR7 rat basophilic leukaemia (RBL)-2H3 transfectants.
Approx. Protein Concentrations
IgG concentration 0.05 mg/ml
Approx. Protein Concentrations
IgG concentration 0.05 mg/ml
Approx. Protein Concentrations
IgG concentration 0.1 mg/ml
Approx. Protein Concentrations
IgG concentration 1.0 mg/ml
Fusion Partners
Spleen cells from immunised Lou/c rats were fused with cells of the mouse X63.Ag8.653 myeloma cell line.

Storage Information

Storage
Store at +4oC or at -20oC if preferred.
Storage in frost-free freezers is not recommended.
This product should be stored undiluted. This product is photosensitive and should be protected from light.

Avoid repeated freezing and thawing as this may denature the antibody. Should this product contain a precipitate we recommend microcentrifugation before use.
Storage
Store at +4oC or at -20oC if preferred.
Storage in frost-free freezers is not recommended.
This product should be stored undiluted. This product is photosensitive and should be protected from light.

Avoid repeated freezing and thawing as this may denature the antibody. Should this product contain a precipitate we recommend microcentrifugation before use.
Storage
Store at +4oC or at -20oC if preferred.

This product should be stored undiluted.

Storage in frost free freezers is not recommended. This product is photosensitive and should be protected from light.

Avoid repeated freezing and thawing as this may denature the antibody. Should this product contain a precipitate we recommend microcentrifugation before use.
Storage
Store at +4oC or at -20oC if preferred.
Storage in frost-free freezers is not recommended.
This product should be stored undiluted. Avoid repeated freezing and thawing as this may denature the antibody. Should this product contain a precipitate we recommend microcentrifugation before use.
Storage
Store at +4oC.

DO NOT FREEZE

This product should be stored undiluted. This product is photosensitive and should be protected from light. Should this product contain a precipitate we recommend microcentrifugation before use.
Shelf Life
18 months from date of despatch.
Shelf Life
18 months from date of despatch.
Shelf Life
18 months from date of despatch.
Shelf Life
18 months from date of despatch.
Shelf Life
12 months from date of reconstitution.

More Information

UniProt
P47774 Related reagents
Entrez Gene
Ccr7 Related reagents
GO Terms
GO:0016021 integral to membrane
GO:0006935 chemotaxis
GO:0006955 immune response
GO:0009897 external side of plasma membrane
GO:0016493 C-C chemokine receptor activity
Acknowledgements
This product is provided under an intellectual property licence from Life Technologies Corporation. The transfer of this product is contingent on the buyer using the purchase product solely in research, excluding contract research or any fee for service research, and the buyer must not sell or otherwise transfer this product or its components for (a) diagnostic, therapeutic or prophylactic purposes; (b) testing, analysis or screening services, or information in return for compensation on a per-test basis; (c) manufacturing or quality assurance or quality control, or (d) resale, whether or not resold for use in research. For information on purchasing a license to this product for purposes other than as described above, contact Life Technologies Corporation, 5791 Van Allen Way, Carlsbad CA 92008 USA or outlicensing@thermofisher.com
Acknowledgements
This product is provided under an intellectual property licence from Life Technologies Corporation. The transfer of this product is contingent on the buyer using the purchase product solely in research, excluding contract research or any fee for service research, and the buyer must not sell or otherwise transfer this product or its components for (a) diagnostic, therapeutic or prophylactic purposes; (b) testing, analysis or screening services, or information in return for compensation on a per-test basis; (c) manufacturing or quality assurance or quality control, or (d) resale, whether or not resold for use in research. For information on purchasing a license to this product for purposes other than as described above, contact Life Technologies Corporation, 5791 Van Allen Way, Carlsbad CA 92008 USA or outlicensing@thermofisher.com
Regulatory
For research purposes only

Applications of CD197 antibody

This product has been reported to work in the following applications. This information is derived from testing within our laboratories, peer-reviewed publications or personal communications from the originators. Please refer to references indicated for further information. For general protocol recommendations, please visit the antibody protocols page.
Application Name Verified Min Dilution Max Dilution
Flow Cytometry Neat *
Flow Cytometry Neat 1/10
Flow Cytometry Neat *
Flow Cytometry 1/25 1/100
Immunoprecipitation
Flow Cytometry Neat
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Where this antibody has not been tested for use in a particular technique this does not necessarily exclude its use in such procedures. Suggested working dilutions are given as a guide only. It is recommended that the user titrates the antibody for use in their own system using appropriate negative/positive controls.
Flow Cytometry
Use 20ul of the suggested working dilution to label 106 cells in 100ul.

The Fc region of monoclonal antibodies may bind non-specifically to cells expressing low affinity Fc receptors. This may be reduced by using SeroBlock FcR (
Flow Cytometry
Use 10ul of the suggested working dilution to label 106 cells in 100ul
Flow Cytometry
Use 20ul of the suggested working dilution to label 106 cells in 100ul.

The Fc region of monoclonal antibodies may bind non-specifically to cells expressing low affinity Fc receptors. This may be reduced by using SeroBlock FcR (
BUF041A/B).
Flow Cytometry
Use 10ul of the suggested working dilution to label 106 cells in 100ul
Flow Cytometry
Use 20ul of the suggested working dilution to label 106 cells in 100ul.

The Fc region of monoclonal antibodies may bind non-specifically to cells expressing low affinity Fc receptors. This may be reduced by using SeroBlock FcR (BUF041A/B).

Secondary Antibodies Available

Description Product Code Pack Size Applications List Price Quantity
Goat anti Rat IgG:Alk. Phos. (Mouse Adsorbed) STAR131A 1 ml C E P WB
Goat anti Rat IgG:Biotin (Mouse Adsorbed) STAR131B 0.5 mg C E IF P WB
Rabbit F(ab')2 anti Rat IgG:Dylight®800 STAR16D800GA 0.1 mg F IF WB
Rabbit F(ab')2 anti Rat IgG:FITC STAR17B 1 mg F
Rabbit F(ab')2 anti Rat IgG:HRP STAR21B 1 mg C E P RE
Goat F(ab')2 anti Rat IgG:FITC (Mouse Adsorbed) STAR69 0.5 ml F
Goat anti Rat IgG:DyLight®649 (Mouse Adsorbed) STAR71D649GA 0.1 mg F IF
Goat anti Rat IgG:Dylight®800 (Mouse Adsorbed) STAR71D800GA 0.1 mg F IF WB
Goat anti Rat IgG:HRP (Mouse Adsorbed) STAR72 0.5 mg C E P
Goat F(ab')2 anti Rat IgG:RPE (Mouse Adsorbed) STAR73 0.5 ml F

Negative Isotype Controls Available

Description Product Code Pack Size Applications List Price Quantity
Rat IgG2a Negative Control:Alexa Fluor® 488 MCA1212A488 100 Tests/1ml F
Rat IgG2a Negative Control:Alexa Fluor® 647 MCA1212A647 100 Tests/1ml F
Rat IgG2a Negative Control:FITC MCA1212F 100 Tests F
Rat IgG2a Negative Control MCA1212 1 ml E F
Rat IgG2a Negative Control:RPE MCA1212PE 100 Tests F

Useful Reagents Available

Description Product Code Pack Size Applications List Price Quantity
Mouse Seroblock FcR BUF041A 0.1 mg F
Mouse Seroblock FcR BUF041B 0.5 mg F
Mouse Seroblock FcR BUF041A 0.1 mg F
Mouse Seroblock FcR BUF041B 0.5 mg F
Mouse Seroblock FcR BUF041A 0.1 mg F
Mouse Seroblock FcR BUF041B 0.5 mg F
Mouse Seroblock FcR BUF041A 0.1 mg F
Mouse Seroblock FcR BUF041B 0.5 mg F

Product Specific References

References for CD197 antibody

  1. Ritter, U. et al. (2004) Analysis of the CCR7 expression on murine bone marrow-derived and spleen dendritic cells.
    J Leukoc Biol. 76 (2): 472-6.
